Danh mục nội dung: Chuyên mục chính/2. Thiết bị đo lường và kiểm tra điện tử/2.2. Thiết bị thu thập dữ liệu, đo lường & cảm biến môi trường (Data Logger and Enviroment Sensors)



  PD3129: Thiết bị đo thứ tự pha Hioki PD3129
  Part#: HIOKI PD3129
  Giá (chưa VAT): 4.050.000đ
  Ghi chú: PHASE DETECTOR - Máy đo sai pha
  Nhãn hiệu: HIOKI (Nhật Bản/ Japan)
  [ Tài liệu Datasheet ]   [ Báo giá Quotation sheet ]   [ Shopping Shopping now ]   [ Views: 5278 ]   2022-01-04
 ◊ Đặc điểm chính:
Chức năng : Đo sai pha
Phương pháp phát hiện:  Cảm ứng  (không tiếp xúc)
Đường kính kìm : φ 2.4 mm (0.09 inch) to 17 mm (0.67 inch)
Dải điện áp : 3-phase 70 ~ 600V AC
Dải tần số : 45 Hz ~ 66 Hz
Cấp đo lường : CATIII 600V
Tiêu chuẩn áp dụng : Safety: EN61010 / EMC : EN61326
Hiển thị :
    + Phát hiện pha : hiển thị LED
    + Kiểm tra pin  : Pin yếu Đèn ON nhấp nháy
Tự động tắt nguồn
Nguồn : AA × 2
Kích thước : 70mm W x 75mm H x 30mm
Khối lượng : 200g (7.1 oz)
Nhiệt độ hoạt động : 0 ~ 40°C (32 ~ 104°F), max. 80 % rh
Nhiệt độ lưu trữ : -20 ~ 60°C (-4 ~ 140°F), max. 80% rh
Phụ kiện : Hộp đựng, pin, HDSD

 ◊ Mô tả chi tiết:
Hioki’s non-contact voltage detection and measurement technology places efficiency and safety as priority considerations with the goal of protecting customers that need to conduct on-site electrical work as part of renovations and expansions of manufacturing plants and buildings. Model PD3129-10 is a non-contact phase rotation meter that detects the phase of electrical current flow within insulated wires without using metallic contact voltage clips. The green arrow indicates normal phase, which can be useful for visual reports that document the proper completion of electrical work.

CAT IV 600 V, CAT III 1000 V

Key Features
• Simply clip clamps onto wire insulation
• Green LED arrow clearly shows phase direction, perfect for visual reports
• CAT III 1000V
• Rotating LED indicator shows the phase sequence for a 3-phase power supply at a glance
• Intermittent beeps signal positive phase; continuous tone signals reverse phase
• Magnetic base allows the instrument to be secured on a distribution panel

Easy-to-understand detection of normal phase with lit arrow

The arrow in the center of the instrument turns green to indicate normal phase. In this way, normal phase can be recognized at a glance. In addition, the arrow shows up clearly in photographs, making the PD3129 ideal for documenting proper installation in end-of-project reports.











Safe, no-metal-contact design

The PD3129 uses no-metal-contact clips that need only be clipped to the outside of each insulated wire, allowing phase to be detected safely.

















Magnetic back for maximum work efficiency

Four magnets on the back of the instrument allow it to be secured in place on distribution panels. By leaving your hands free for other tasks, this feature dramatically boosts work efficiency.



 Thêm chi tiết:
